| MonitorSection |
Picture size |
9 inches (diagonal) wide |
| W x H |
|
| Display system |
TN LCD panel |
| Drive system |
TFT active matrix system |
| Number of pixels |
1,843,200 |
| 1024H x 600V x RGB |
| Effective pixels |
99.99% |
| Pixel arrangement |
RGB striped arrangement |
| Back lighting |
LED |
| USB I/FSection |
USB Standard |
USB2.0 High Speed |
| Connector |
Type-A |
| File System |
FAT32/ exFAT |
| Maximum Power Supply Current |
DC5V(DC logo) 2.1A |
| D/A Converter |
24 Bit |
| Audio Decoder |
MP3/ WMA/ WAV/ AAC/ FLAC |
| Video Decoder |
MPEG1/ MPEG2/ MPEG4/ H.264/ MKV |
| Wi-FiSection |
Frequency response |
192k Sampling |
20 - 20,000 Hz |
| 96k Sampling |
20 - 20,000 Hz |
| 48k Sampling |
20 - 20,000 Hz |
| 44.1k Sampling |
20 - 20,000 Hz |
| IEEE Standard |
802.11 a/ n/ ac |
| Frequency Range |
5GHz (5.745～5.825GHz) |
| Channels |
149ch |
|
Auto(149,153,155,157,161ch) |
| Transfer rates (MAX) |
11a:54 Mbps / 11b: 11 Mbps |
|
11g: 54 Mbps / 11n:150 Mbps / 11ac:433 Mbps |
| BluetoothSection |
Bluetooth Specification Version |
Bluetooth V5.0 |
| Frequency |
2.402 - 2.480 GHz |
| RF Output Power (E.I.R.P.) |
+0.7 dBm (AVE), Power Class 2 |
| Maximum Communication range |
Line of sight approx.10m |
| Audio Codec |
SBC / AAC |
| Multi Profile Support |
Multi Profile |
| Profile |
HFP(Hands Free Profile) 1.7 |
| SPP(Serial Port Profile) 1.2 |
| A2DP(Advanced Audio Distribution Profile) 1.3 |
| AVRCP(Audio/Video Remote Control Profile) 1.6 |
| PBAP(Phonebook Access Profile) 1.2 |
| FM |
Frequency range (Frequency step) |
87.5 - 108 MHz (50kHz) |
| Usable sensitivity |
16.2dBf |
| S/N:30dB |
1.8μV/75Ω |
| Frequency response(±3.0dB) |
30Hz - 14kHz |
| S/N Ratio(dB) |
50dB (MONO) |
| Stereo separation |
35 dB (1 kHz) |
| AM |
Frequency range (Frequency step) |
531 - 1611 kHz (9kHz) |
| Usable sensitivity |
99μV (40 dBμ) |
| Video |
Color system of external video input |
NTSC/ PAL |
| Rear view camera input level (RCA) |
1 Vp-p / 75 Ω |
| Video Output level (RCA) |
1 Vp-p / 75 Ω |
| Audio |
Maximum Power (Front&Rear) |
50Wx4 |
| Full Bandwidth Power (Front&Rear)(at less than 1%THD) |
22Wx4 |
| Output frequency band |
20 - 20,000 Hz |
| Preout level (V) |
2.5 V / 10 kΩ |
| Preout impedance (Ω) |
1.4 kΩ |
| Speaker Impedance (Ω) |
4 - 8 Ω |
| Equalizer |
13 Band |
| Band |
Frequency |
62.5/ 100/ 160/ 250/ 400/ 630/ 1k/ 1.6k/ 2.5k/ 4k/ 6.3k/ 10k/ 16k Hz |
| Level |
-09 - +09 (-9dB - +9dB) |
| Q |
- |
| HPF |
Frequency |
Through/ 30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/ 150/ 180/ 220/ 250 Hz |
| Slope |
-6/ -12/ -18/ -24 dB/Oct. |
| Gain |
-8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB |
| LPF |
Frequency |
30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/ 150/ 180/ 220/ 250 Hz/ Through |
| Slope |
-6/ -12/ -18/ -24 dB/Oct. |
| Gain |
-8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB |
| General |
Operating voltage |
12V DC car battery |
| Main Unit Installation size W x H x D(w/o sleeve) |
229 x 130.5 x 100.8mm |
| Weight |
Main unit |
1.33 kg |
